TECHNICAL PARAMETERS

BODY

Die cast aluminum

Waterproof grade: IP65

Bracket: widened design for greater stability

LIGHT SOURCE

Light source: 18x20W RGBWA UV LED

LED lifespan: 50000 hours

OPTIC

Beam angle: 20 °

Dimming: No jitter

CCT shortcut key (color temperature 2000K-10000K adjustable)

CONTROL AND PROGRAM

6 touch buttons

Control panel: OLED display screen Control protocol:

Wired DMX512, IR remote control, APP (WIFI) (supports Apple and Android), 2.4G wireless DMX512, RDM

DMX channel mode: 4 modes

DMX channels: 2/6/8/11 channels

Software upgrade: Upgrade software through DMX connection

ELECTRICAL

Input power range: AC110V-240V,50/60Hz

Power: 120W

Power socket: Waterproof ture1powercon in&out (Seetronic brand)

Signal: 3-Pin waterproof XLR socket in&out

BATTERY

Battery capacity:24000mAh

Charging and discharging times: 500 times

Charging time: 6.5H

Full power on: 3H

Auto: Self run 6H

monochrome run：15H

WORK ENVIRONMENT

Maximum ambient temperature: 45 ° C

Minimum operating temperature: 0 ° C

Maximum surface temperature: 65 °

Protection level: IP65

INSTALL

Can be installed horizontally/vertically/upside down Quick lock hole at the bottom

Safety rope hole

FACTORY CONFIGURATION

Instruction manual

Power line/DMX signal line/remote control

OPTIONAL PARTS

Flightcase Clamps

Quick lock component  Magnetic diffusion filter

 Barn door
