Power

Input voltage: AC100-240V 50/60Hz

Power consumption: 200W

 Fixture

IP rating: IP20

Cooling method: fan cool

Max ambient temp: 45℃

Case color: black

 Lamp

Lamp: 150W white LED module +40*0.2W RGB 3in1 LED

Color Temp: 9000K

Average lifespan: 50,000 hours

 Control

DMX channel: 19CH

DMX connector: 3Pin XLR input/output

Power connector: PowerCon input

Control mode: DMX/master-slave/auto/sound/RDM

Pan: 540º16bits, Tilt: 270º16bits

Precise and fast Pan/Tilt movements

Motorized focus, frost, split color,rainbow effect

3-phase motor for Pan/Tilt, automatic position correction

Static gobo wheel: 12gobos plus open+5 glass gobos

Static color wheel: 14colors plus open

Prism 1: 8-facet rotating

Prism 2: 8+16-facet rotating

Full color LCD display with 5 buttons

With RMD function and software upload via DMX cable

 Color effect

Color: 9 colors+open, split color,rainbow effect

Beam angle: 1.8°

Dimming: 0-100% linear

Strobe: 0-25Hz

Lux :15500Lux @ 5m

Dimension

Product dimension:  300*220*560mm

N.W: 7.6KG
